Á¦Ç° »ç¾ç (Specifications)

1. Model : CAS-A2 (2 wire) & CAS-A3 (3 wire)
2. Range : -14.7 ~ 3000 psig
3. Over range : 150% of Full scale
4. Burst Pressure : 300% of Full scale
5. Accuracy : ¡¾ 0.25 % of Full scale
6. Repeatability : ¡¾ 0.1% of Full scale
7. Output : 4~20 mA (2 wire or 3 wire)
8. Operating Temperature : -20 ~ 60 ¡É
9. Humidity : 0 to 95% RH,
10. Power : 12 to 30 VDC with reserve polarity
                 protection
11. Electromagnetic compatibility (EMC & EMI)
   ¡° CE ¡± according to EN61000-6-2 : 2001
      EN61000-6-4 :2001
   ¡° S ¡± - according to
      EN55011 : 1998/A1:1999/A2:2002
      & EN61000-6-2:2001
12. Material :
   Sensing element : Thin Film Sensor
   Wetted Surface : Reduced-sulfur 316L and
                            Hastelloy C-22
   Wetted Surfaces Finish : EP to 3~5Ra :
   Housing Material : 300 series stainless steel
