1. Model : CAS-A2 (2wire) & CAS-A3 (3wire)
2. Range : Mini _ Max. 200 kg
                 Platform _ MAX. 50 Ton
3. Over range : 150% of Full scale
4. Accuracy : ± 0.1 % of Full scale
5. Repeatability : ± 0.1 % of Full scale
6. Output : 4~20 mA (2 wire or 3 wire)

7. Operating Temperature : -20 ~ 60¡É
8. Humidity : 0 to 95% RH, Pig-tail Model
9. Power : 12 to 30 VDC with reserve
                 polarity protection
10. Electromagnetic compatibility (EMC & EMI)
    ¡° CE ¡± according to EN61000-6-2:2001
     EN61000-6-4:2001
    ¡° S ¡± - according to
     EN55011:1998/A1:1999/A2:2002
     & EN61000-6-2:2001
11. Material :
     Cover : Stainless Steel
     Base : Steel
     Load cell : Stainless Steel
12. Size : Available to produce all special size
